Product Details:
|
Warranty: | 3years | Chargeable: | Yes |
---|---|---|---|
Application: | BOATS, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Security System, UPS, WIND SYSTEM, Lighting, Medical Equipment | Weight: | 19.2kg |
Product Name: | Lead Acid Battery | Size: | 348*167*178mm |
Internal Resistance: | 7.8mΩ | Operating Temperature Range: | Charge: 0 C~40℃,Discharge: -20 C~55℃,Storage: -15 C~50℃ |
Capacity Affected By Temperature: | 40℃ 103% 25℃100% 0℃85% | Float Charging Voltage: | 13.5 To 13.8V;Recom.13.5V |
Equalizing Charging Voltage: | 13.8 To 14.1V; Recom.14.1 | Float Charging Temp.Coefficient: | -18mV/℃ |
Equalizing Charging Temp. Coefficient: | -24mV/℃ | Max.Charging Current: | 16.3A |
Warranty | 3years |
Chargeable | Yes |
Application | BOATS, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Security system, UPS, WIND SYSTEM, Lighting, medical equipment |
Brand Name | LEOCH |
Model Number | DJM12-65S |
Weight | 19.2kg |
Product name | Lead Acid Battery |
Size | 348*167*178mm |
Internal Resistance | 7.8mΩ |
Operating Temperature Range | Charge: 0 C~40℃,Discharge: -20 C~55℃,Storage: -15 C~50℃ |
Capacity affected by Temperature | 40℃ 103% 25℃100% 0℃85% |
Float Charging Voltage | 13.5 to 13.8V;Recom.13.5V |
Equalizing Charging Voltage | 13.8 to 14.1V; Recom.14.1 |
Float Charging Temp.Coefficient | -18mV/℃ |
Equalizing Charging Temp. Coefficient | -24mV/℃ |
Max.Charging Current | 16.3A |
Max.Continuous Discharge Current | 186A |
Month Self Discharge | 2% (20℃) |
Terminal | T6 [Female M6] |
Container Material | ABS [UL94-HB] |
